Industrial Inverter
Three-phase variable frequency drives for motor speed control and factory automation. 0.75kW to 630kW, V/F and vector control, Modbus / Profibus communication, IEC 61800-5 standard.
- Power range 0.75kW to 630kW — covers light duty to heavy industrial applications
- Three-phase input: 380V / 480V / 690V AC
- Control modes: V/F, Sensorless Vector Control (SVC) and Field Oriented Control (FOC)
- Overload capacity: 150% for 60 seconds, 180% for 10 seconds
- Communication: Modbus RTU, Profibus DP, CANopen — PLC integration ready
- Protection class IP20 standard, IP54 cabinet option for harsh environments
MOQ / Project-based
Lead Time / 15-30 days
Supply / B2B / Wholesale
Origin / China
Product Overview
Industrial inverters — also known as variable frequency drives (VFD) or variable speed drives (VSD) — control the speed and torque of AC motors by varying the output frequency and voltage. They are the primary method of motor speed control in modern industrial automation and process control systems.
RichingPower supplies three-phase industrial inverters from 0.75kW to 630kW, covering light-duty applications such as fans and pumps through to heavy-duty applications such as hoists, cranes and compressors. All models support V/F, sensorless vector and FOC control modes.
Standard models are IP20 rated for panel installation. IP54 enclosed versions are available for direct mounting in dusty or wet industrial environments without a separate control panel enclosure.
Control Mode Selection
Open-loop, simple setup — fans, pumps, conveyors with low dynamic requirement
Good torque at low speed — machine tools, compressors, mixers
High-precision torque control — cranes, hoists, servo-like applications
| Parameter | Specification |
|---|---|
| Power Range | 0.75kW – 630kW |
| Input Voltage | 3-phase 380V / 480V / 690V AC (±15%) |
| Output Voltage | 0 to input voltage, 3-phase |
| Output Frequency | 0 – 500Hz |
| Control Mode | V/F, Sensorless Vector (SVC), FOC |
| Overload Capacity | 150% / 60s (normal duty); 180% / 10s (heavy duty) |
| Efficiency | >97% |
| Protection Class | IP20 (standard); IP54 (enclosed option) |
| Communication | Modbus RTU, Profibus DP, CANopen, PROFINET (optional) |
| Operating Temperature | –10°C to +50°C (derating above 40°C) |
| Applicable Standards | IEC 61800-5-1, IEC 61800-3, CE, RoHS |
Industrial inverters supplied by RichingPower are certified to the following standards.
Industrial inverters are used wherever AC motor speed control is required. Drive selection depends on motor power, load type, control precision and communication protocol.
Request a Quotation
Send us your motor specifications and application details. Our team will recommend the correct drive rating and control mode within 24 hours.
What to include in your enquiry:
We reply within 24 hours with a recommended model and quotation.
Send Enquiry
Contact us via the enquiry form or WhatsApp for a faster response.
Go to Enquiry Form → WhatsApp Us
