Electrical Cables
Data Center Cable
Power cables, control cables and network cables for data center electrical infrastructure. LSZH rated, high fire performance, suitable for raised floor, cable tray and plenum installation environments.
KEY FEATURES
- LSZH outer sheath — low smoke, zero halogen for confined space installations
- Fire resistant options rated to IEC 60331 / BS 6387 Cat C (90 min circuit integrity)
- Covers all data center cable categories: LV power, control and Cat6 / Cat6A network
- Suitable for raised floor, cable tray, conduit and plenum installation
- Consolidated project supply — power, control and network cables from one source
- IEC 60502, IEC 60331, ISO/IEC 11801 and TIA-568 standards available
MOQ / Project-based
Lead Time / 15-30 days
Supply / B2B / Wholesale
Origin / China
Product Overview
Data center cable procurement covers multiple cable categories within a single project: LV power cables from the main distribution board to UPS and PDU units, control cables for monitoring and switching systems, and structured network cables for IT infrastructure.
Data centers have specific requirements for fire performance, low smoke emission and halogen-free materials. RichingPower supplies all three cable categories with LSZH sheath, fire-resistant and fire-rated options suitable for raised floors, cable trays and plenum spaces.
We support consolidated project procurement covering all cable categories. Buyers can submit a full cable schedule for a single quotation covering power, control and network cables together.
Fire Performance Classifications
IEC 60332-1 / 60332-3 — does not propagate flame
IEC 61034 — reduced smoke emission under fire
IEC 60754-1 — no toxic halogen gases when burning
IEC 60331 / BS 6387 Cat C — 90 min circuit integrity at 950°C
| Category | Type | Key Specification |
|---|---|---|
| Power Cable | LV Power Cable (LSZH) | 0.6/1kV, Cu, XLPE insulation, LSZH sheath, IEC 60502-1 |
| Fire Resistant Cable | 0.6/1kV, Cu, mica tape, 90 min circuit integrity, IEC 60331 / BS 6387 | |
| Control Cable | Shielded Control Cable | 0.6/1kV, Cu, overall foil + braid shield, LSZH sheath |
| Instrumentation Cable | 300/500V, individual + overall screen, LSZH, IEC 60227 | |
| Network Cable | Cat6 UTP | 4-pair, 250MHz, solid copper, 1Gbps, TIA-568-C / ISO 11801 |
| Cat6A SFTP | 4-pair, 500MHz, shielded, 10Gbps to 100m, PoE++ support | |
| Patch Cords | Cat6 / Cat6A, 0.5m–10m, RJ45, boot color-coded |
Data center cables supplied by RichingPower comply with the following standards. Please specify fire performance requirement and applicable standard when submitting an enquiry.
Data center cable procurement typically covers multiple categories in a single project. The selection of fire performance rating and cable category depends on the installation zone and circuit criticality.
Request a Quotation
Data center cable procurement typically covers multiple categories. Send us your full cable schedule for a consolidated quotation covering power, control and network cables.
What to include in your enquiry:
We support consolidated quotation across all cable categories and reply within 24 hours.
